St Johns Park SOW Summary;
Ceilings
• PBD-01 = 13mm PB Suspended Ceiling• PBD-02 = 13mm WR Suspended Ceiling• PBD-03 = Boardroom, Boral Echostop S8 – normal suspension system• PBD Ceilings – Square Set• All PB Ceiling to be Level 5 • Allowed for 7 Access Panels – 600x600 Rondo Panther or Similar• ACT-01 = Armstrong 3643 Dune 600x600 Tegular Tiles, Rondo Suspension System• ACT-01 = 25mm Aluminium flat bar to wall/ceiling – match colour to skirting – no mention on type of wallangle so just do L shape one to be similar to square set• Insulation over all ceilings, 185mm Bradford Gold Ceiling Batts R3.5• Stair 1 and Lobby = 6mm CEMENTEL Wallboard SE – Expressed Joints with sealant, NO Plastic systems to be used. No mention on wall/ceiling junction, so do similar to PB• Wavebar above walls as per plan• Curved Grid required at some sections• PB Ceilings Square Set• Grid Ceiling Shadowline Wall Angle• 25mm Flat Bat to Partitions to ceiling
Walls
• Soundcheck to – CEO Office / CEO Meeting Room / Boardroom / Disabled Toilet?• Lobby Wall – 13mm MRFR Board, Inner Face 9mm CFC – need to check this on site – we have allowed for this wall and needs to be done prior to external CFC by others• Lobby Wall – Scope says Rondo MAXIFrame – refer drw 4201 detail 7• Window Sills, MDF by us, changed from folded aluminium• External Columns 3 layers 13mm FR direct, internal columns to be within wall
Wall Types
• WT-01 – 13RE / 76mm / 13WR / INSUL-01• Sound Rated PB to CEO Office, CEO Meeting, Boardroom• WT-02 – 13 RE / 92mm / INSUL-01• WT-03 – 28mm Furring Channel / 13RE or 13WR – Plans show stud frame so check on site• WT-04 – 13 RE / 51mm Stud / 13 WR• WT-06 – ½ height wall with vertical fins above / 76mm Stud / 13 RE• WT-07 Shaft Wall to roof, see detail. Shaftliner, CH Stud, 2x13mm FR• WT-09 – 13WR / 51mm Stud / 54mm Cavity/ INSUL-01 / 51mm Stud / 13WR• WT-10 Refer DEM – MAXIframe 450 centres, 13mm MRFR outside, 9mm EXOTEC Inside – check with Sean if expressed joints as not specified• WT-11 – Cover Glazing / 13RE inside glazing unit / Metal stud in window opening / Furring channel below / INSUL-02 in window opening / 13WR inside face• -• Note, No Quiet Studs allowed for as per original sow request.
Insulation
• Ceilings - 185mm Bradford Gold Ceiling Batts R3.5• Cut ceiling insulation to 600x600 to small sections only for Access Panel usage• Walls – W01 – W02 – W03b – W08o 90mm Bradford Gold HP Wall Batts R2.5• Walls – W06 – W07 – Accessible WCo 60mm Bradford Glasswool Building Blanket Plain R1.3• Walls – W09 to separate open lobby and office adjacent to main entry dooro 90mm Bradford Gold HP Wall Batts R2.7
Glazed Partitions
• 10.38mm clear laminated glass• Alspec McArthur 101.6mm x 44.4mm commercial grade clear anodised centre pocket (equal or similar)• Door Frames – Alspec McArthur 101.6mm x 44.4mm commercial grade• 100mm clear anodised skirting• No Film included in quote• Door 23 excluded• We installing Solid Core Doors and Criterion Hardware.• Hardware allowed;o 801572 – Mortice Primary Locko 803150 – Ext Plate with Lever + Cylinder Holeo 803650 – Int Plate with Lever – classroom styleo 813290 Half Moon Door Stopo 811939.1 Quickfix Hinges• Door closer to Door D02 only• Door Hinges, specified 4 hinges per door.
Changes to Plans
• V9 approved 13/4/20o Str Room next to Stairs 2o Change internal walls & ceiling to 1 hour fire rated wallo Change door and frame to 1 hour fire ratedo Ensure Hardware is 1 hour fire ratedo Ensure toilet remains WR boardo No work to external walls
Ceilings
• PBD-01 = 13mm PB Suspended Ceiling• PBD-02 = 13mm WR Suspended Ceiling• PBD-03 = Boardroom, Boral Echostop S8 – normal suspension system• PBD Ceilings – Square Set• All PB Ceiling to be Level 5 • Allowed for 7 Access Panels – 600x600 Rondo Panther or Similar• ACT-01 = Armstrong 3643 Dune 600x600 Tegular Tiles, Rondo Suspension System• ACT-01 = 25mm Aluminium flat bar to wall/ceiling – match colour to skirting – no mention on type of wallangle so just do L shape one to be similar to square set• Insulation over all ceilings, 185mm Bradford Gold Ceiling Batts R3.5• Stair 1 and Lobby = 6mm CEMENTEL Wallboard SE – Expressed Joints with sealant, NO Plastic systems to be used. No mention on wall/ceiling junction, so do similar to PB• Wavebar above walls as per plan• Curved Grid required at some sections• PB Ceilings Square Set• Grid Ceiling Shadowline Wall Angle• 25mm Flat Bat to Partitions to ceiling
Walls
• Soundcheck to – CEO Office / CEO Meeting Room / Boardroom / Disabled Toilet?• Lobby Wall – 13mm MRFR Board, Inner Face 9mm CFC – need to check this on site – we have allowed for this wall and needs to be done prior to external CFC by others• Lobby Wall – Scope says Rondo MAXIFrame – refer drw 4201 detail 7• Window Sills, MDF by us, changed from folded aluminium• External Columns 3 layers 13mm FR direct, internal columns to be within wall
Wall Types
• WT-01 – 13RE / 76mm / 13WR / INSUL-01• Sound Rated PB to CEO Office, CEO Meeting, Boardroom• WT-02 – 13 RE / 92mm / INSUL-01• WT-03 – 28mm Furring Channel / 13RE or 13WR – Plans show stud frame so check on site• WT-04 – 13 RE / 51mm Stud / 13 WR• WT-06 – ½ height wall with vertical fins above / 76mm Stud / 13 RE• WT-07 Shaft Wall to roof, see detail. Shaftliner, CH Stud, 2x13mm FR• WT-09 – 13WR / 51mm Stud / 54mm Cavity/ INSUL-01 / 51mm Stud / 13WR• WT-10 Refer DEM – MAXIframe 450 centres, 13mm MRFR outside, 9mm EXOTEC Inside – check with Sean if expressed joints as not specified• WT-11 – Cover Glazing / 13RE inside glazing unit / Metal stud in window opening / Furring channel below / INSUL-02 in window opening / 13WR inside face• -• Note, No Quiet Studs allowed for as per original sow request.
Insulation
• Ceilings - 185mm Bradford Gold Ceiling Batts R3.5• Cut ceiling insulation to 600x600 to small sections only for Access Panel usage• Walls – W01 – W02 – W03b – W08o 90mm Bradford Gold HP Wall Batts R2.5• Walls – W06 – W07 – Accessible WCo 60mm Bradford Glasswool Building Blanket Plain R1.3• Walls – W09 to separate open lobby and office adjacent to main entry dooro 90mm Bradford Gold HP Wall Batts R2.7
Glazed Partitions
• 10.38mm clear laminated glass• Alspec McArthur 101.6mm x 44.4mm commercial grade clear anodised centre pocket (equal or similar)• Door Frames – Alspec McArthur 101.6mm x 44.4mm commercial grade• 100mm clear anodised skirting• No Film included in quote• Door 23 excluded• We installing Solid Core Doors and Criterion Hardware.• Hardware allowed;o 801572 – Mortice Primary Locko 803150 – Ext Plate with Lever + Cylinder Holeo 803650 – Int Plate with Lever – classroom styleo 813290 Half Moon Door Stopo 811939.1 Quickfix Hinges• Door closer to Door D02 only• Door Hinges, specified 4 hinges per door.
Changes to Plans
• V9 approved 13/4/20o Str Room next to Stairs 2o Change internal walls & ceiling to 1 hour fire rated wallo Change door and frame to 1 hour fire ratedo Ensure Hardware is 1 hour fire ratedo Ensure toilet remains WR boardo No work to external walls
